Completion Date: |
May 1987 |
Rentable Square Feet: |
11,100 sq. ft. (approx.) |
Structure: |
Concrete Tilt with wood glulam joist and deck. |
Exterior: |
Concrete panels with 100 % acrylic paint finish. |
Glazing: |
Reflective Blue on 2nd level; Graylite 14 on 1st floor. |
Lobby Finishes: |
Floors: |
Ceramic tile. |
Entry: |
One story structure with glass on two sides. |
Stair to Second Floor: |
Traditional turned wood stair balusters with carpeted treads |
Entry Doors: |
Unit A: 3-0 x7-0 Oak, Units B-D: 3-0x7-0 glass store front doors. |
Lighting: |
Recessed lighting within a soffited ceiling. |
Typical Floors: |
Column spacing: |
24 foot spacing. |
Ceiling: |
2 x 4 white acoustical tiles; drywall ceiling in lobby entry. |
Doors: |
All solid wood , raised panel 3-0 x 8-0 stained finish. |
Finish Hardware: |
Schlage "D" series with satin chrome finish. |
Lighting: |
2 x 4 recessed fluorescent fixtures. |
Windows: |
Blue reflective on second floor, 36 inches from floor; Graylite 14 on first floor, full floor to ceiling window height. |
Ceiling Height: |
8 1/2 feet. |
Restrooms: |
Ceramic tile floors and walls with custom oak cabinets. |
Kitchenette: |
Sink, microwave, under counter refrigerator and sitting area. |
Mechanical, Electrical and Plumbing: |
Cooling: |
Four rooftop units. |
Electrical: |
800 amps, 3 phase per building. |
Loading: |
Surface level. |
Life Safety Systems: |
Fire Detection and monitoring: |
Monitored 24 hours a day by a central station. |
Sprinklers: |
Buildings are fully fire sprinklered. |
Notification: |
Horns and strobes. |
Exiting: |
All exits are fire rated. |
